Smart Interactive Display
MW3586-U-E
| Panel | Description |
| Backlight | DLED backlight |
| Panel size | 86 inches |
| Resolution | 3840*2160 |
| Brightness (cd/m²) | 350 |
| Contrast Ratio | 1200:1 |
| Response Time (ms) | 8 |
| Color Support | 1.07B |
| Viewing Angle (H/V) | 178°/178° |
| System | Description |
| CPU | RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G) |
| CPU Frequency | 2.4GHz |
| RAM/ROM | DDR4: 8GB eMMC: 64GB |
| System Compatibility | Android 12.0 |
| Touch | Description |
| Touch Control | Infrared touch screen, 20-point multi-touch at most |
| Touch Precision (mm) | ±1 |
| Recognizable Object | 5 points 2mm |
| Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare |
| Touch Response Time (ms) | ≤10 |
| Touchscreen Input | Opaque objects (e.g. finger, pen, etc.) |
| Interface | Description |
| Video Input | 3*HDMI IN (4K@60) |
| Video Output | 1*HDMI OUT (4K@60) |
| Audio Input | 1*AUDIO IN |
| Audio Output | 1*AUDIO OUT |
| Other Interfaces | 1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B |
| Network | 2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces |
| Audio | Description |
| Frequency domain | 80Hz～20kHz |
| Speaker | Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) |
| Wi-Fi | Description |
| WiFi Configuration | Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G |
| WiFi Performance | 30 m² coverage, 20m transmission distance in open space |
| Bluetooth | Description |
| Bluetooth Version | 5.2 |
| Bluetooth Performance | 10m transmission distance in open space |
| OSD | Description |
| Multi-Language | 24 (Simplified Chinese、Traditional Chinese、English、Japanese、Arabic、French、Spanish、Portuguese、German、Italian、Dutch、Polish、Korean、Catalan、Galician、Vietnamese、Bulgarian、Kazakh、Russian、Ukrainian、Thai、Uzbek、Hungarian、Croatian) |
| VESA | Description |
| Wall mount hole (mm) | 800*400 |
| Wall mount screw | 4-M8 screw hole |
| General | Description |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Overall Power Consumption （W） | ≤365 (on without OPS) |
| Standby Power Consumption （W） | ＜0.5 |
| Product Dimensions （W*H*D）（mm） | 1967*1173*89 |
| Package Dimensions （W*H*D）（mm） | 2117*1336*247 |
| Weight（Kg） | Net weight: 68.0 Gross weight:79.2 |
| Operating Temperature | 0 to 50°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage temperature | -20 to 60°C |
| Storage humidity | 0% to 95% (non-condensing) |
| Accessories Included | 1*power cord、2*touch pen、1*quick guide |
SKU: n/a
Analog 2mp, Analog Cameras
UAC-B112-F28(40)-W
2MP ColourHunter Fixed Bullet Analog Camera
• 2MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
SKU: n/a
CCTV Cables
UTP Category 5E Cables
| Content of Data Sheet | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product model | CAB-LC2100A-IN/CAB-LC2100B-IN | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product specification | HSYV-5e 4×2×0.50 |  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Test Standard | YD/T1019-2013 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Conductor | Material | OFC(Oxygen free copper) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AWG | 24 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nom.O.D.(mm) | 0.5±0.005 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DC resistance | ≤95 Ω/km | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Insulation | Material | HDPE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.2±0.02 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Diameter | 0.9±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Blue/White- Blue | Green/White-Green | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Orange /White-Orange |
Brown/White-Brown | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pitch | Offset pitch | ≤25 mm |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Cable pitch | ≤140 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sheath | Material | PVC(complies RoHS/REACH) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| External O.D. | 5.1±0.3 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Gray(RAL7046) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tensile strength | >13.5 Mpa | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.55±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Surface Printing | Letter height | 3.0±0.3 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Black | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Print error & Space | 1±0.005 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Case number | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing | Packing | Carton | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Once packing dimension | 350mm*216mm*350mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing dimension | 370mm*460mm*370mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing quantity | 2 cases | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing length | 305±1 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rip-cord | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Ambient temperature | -20℃～60℃ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SKU: n/a
Laptops & Computers
Go to Daily Deals SectionHeadphones
Go to Daily Deals SectionAnalog 2mp, Analog Cameras
UAC-B112-F28(40)-W
2MP ColourHunter Fixed Bullet Analog Camera
• 2MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
SKU: n/a
Analog 5mp, Analog Cameras
UAC-B115-AF28(40)
5MP Fixed IR Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 5mp, Analog Cameras
UAC-T115-AF28(40)
5MP Fixed IR Turret Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 5mp, Analog Cameras
UAC-B115-AF28(40)-W
5MP ColourHunter Fixed Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 8mp, Analog Cameras
UAC-D122-AF28(40)M
2MP LightHunter HD IR Fixed Dome Analog Camera
• High quality imaging with 2MP resolution
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• 3D noise reduction technology delivers clean and sharp images
• Supports 180° horizontal/vertical flip
• OSD configuration menu, easy to operate
• Water and dust resistant (IP67) and vandal-resistant (IK10)
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports digital defog
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• 3D noise reduction technology delivers clean and sharp images
• Supports 180° horizontal/vertical flip
• OSD configuration menu, easy to operate
• Water and dust resistant (IP67) and vandal-resistant (IK10)
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports digital defog
SKU: n/a
IP Camera 4mp, IP Cameras, Owlview
IPC2314LE-ADF28(40)KM-WP
4MP ColorHunter with Wise-ISP Fixed Bullet Network Camera
High quality image with 4MP, 1/1.8″CMOS sensor and F1.0 large aperture lens
4MP (2688*1520)@ 25/20fps; 4MP (2560*1440)@ 25/20fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps;
Ultra 265, H.265, H.264, MJPEG
Colorhunter with Wise-ISP technology ensures 24-hour full-color images
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic
White Light, up to 30m warm light distance
Supports 256 GB Micro SD card
IP67 protection
Support PoE power supply
3-Axis
SKU: n/a
IP Cameras, PTZ Camera
IPC6412LR-X16-VG
2MP 16x LightHunter Network PTZ Dome Camera
• High quality image with 2MP,1/2.8’’ CMOS sensor
• 1920*1080@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• 16X optical zoom allows for closer viewing of subjects
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100m (328ft) IR distance
• Micro SD, up to 256GB
• DC 12V±25% or PoE+ (IEEE 802.3at)
• IP66 ingress protection
• 1920*1080@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• 16X optical zoom allows for closer viewing of subjects
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100m (328ft) IR distance
• Micro SD, up to 256GB
• DC 12V±25% or PoE+ (IEEE 802.3at)
• IP66 ingress protection
SKU: n/a
DVR & NVR
XVR301-16F
Support H.265/H.264 video formats
Support audio over coaxial cable(only for TVI cameras)
Support analog camera upgrade over coaxial cable
Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
16-channel BNC input
Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
HDMI and VGA simultaneous output
Long transmission distance over coaxial cable
Support mainstream cameras of ONVIF and RTSP protocols
SKU: n/a
Monitors & TV
MW-LC22
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 22” |
| Pixel Pitch（H*V）(mm) | 0.24*0.24 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Polish, Czech, Russian, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 493.06*382.69*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 557*370*140 |
| Weight（Kg） | Net Weight:2.3 Gross Weight:3.3 |
| Operation Temperature | 0°C ~ 40 °C |
| Operating Humidity | 20%~85% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Monitors & TV
MW-LC24
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 24″ |
| Pixel Pitch（H*V）(mm) | 0.27*0.27 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Russian, Polish, Czech, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 540.38*417.55*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 601*400*145 |
| Weight（Kg） | Net Weight:3.4 Gross Weight:4.4 |
| Operation Temperature | 0°C ~ 50 °C |
| Operating Humidity | 10%~90% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Smart Interactive Display
MW3586-U-E
| Panel | Description |
| Backlight | DLED backlight |
| Panel size | 86 inches |
| Resolution | 3840*2160 |
| Brightness (cd/m²) | 350 |
| Contrast Ratio | 1200:1 |
| Response Time (ms) | 8 |
| Color Support | 1.07B |
| Viewing Angle (H/V) | 178°/178° |
| System | Description |
| CPU | RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G) |
| CPU Frequency | 2.4GHz |
| RAM/ROM | DDR4: 8GB eMMC: 64GB |
| System Compatibility | Android 12.0 |
| Touch | Description |
| Touch Control | Infrared touch screen, 20-point multi-touch at most |
| Touch Precision (mm) | ±1 |
| Recognizable Object | 5 points 2mm |
| Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare |
| Touch Response Time (ms) | ≤10 |
| Touchscreen Input | Opaque objects (e.g. finger, pen, etc.) |
| Interface | Description |
| Video Input | 3*HDMI IN (4K@60) |
| Video Output | 1*HDMI OUT (4K@60) |
| Audio Input | 1*AUDIO IN |
| Audio Output | 1*AUDIO OUT |
| Other Interfaces | 1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B |
| Network | 2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces |
| Audio | Description |
| Frequency domain | 80Hz～20kHz |
| Speaker | Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) |
| Wi-Fi | Description |
| WiFi Configuration | Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G |
| WiFi Performance | 30 m² coverage, 20m transmission distance in open space |
| Bluetooth | Description |
| Bluetooth Version | 5.2 |
| Bluetooth Performance | 10m transmission distance in open space |
| OSD | Description |
| Multi-Language | 24 (Simplified Chinese、Traditional Chinese、English、Japanese、Arabic、French、Spanish、Portuguese、German、Italian、Dutch、Polish、Korean、Catalan、Galician、Vietnamese、Bulgarian、Kazakh、Russian、Ukrainian、Thai、Uzbek、Hungarian、Croatian) |
| VESA | Description |
| Wall mount hole (mm) | 800*400 |
| Wall mount screw | 4-M8 screw hole |
| General | Description |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Overall Power Consumption （W） | ≤365 (on without OPS) |
| Standby Power Consumption （W） | ＜0.5 |
| Product Dimensions （W*H*D）（mm） | 1967*1173*89 |
| Package Dimensions （W*H*D）（mm） | 2117*1336*247 |
| Weight（Kg） | Net weight: 68.0 Gross weight:79.2 |
| Operating Temperature | 0 to 50°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage temperature | -20 to 60°C |
| Storage humidity | 0% to 95% (non-condensing) |
| Accessories Included | 1*power cord、2*touch pen、1*quick guide |
SKU: n/a
CCTV Cables
UTP Category 5E Cables
| Content of Data Sheet | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product model | CAB-LC2100A-IN/CAB-LC2100B-IN | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product specification | HSYV-5e 4×2×0.50 | |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Test Standard | YD/T1019-2013 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Conductor | Material | OFC(Oxygen free copper) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AWG | 24 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nom.O.D.(mm) | 0.5±0.005 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DC resistance | ≤95 Ω/km | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Insulation | Material | HDPE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.2±0.02 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Diameter | 0.9±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Blue/White- Blue | Green/White-Green | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Orange /White-Orange |
Brown/White-Brown | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pitch | Offset pitch | ≤25 mm |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Cable pitch | ≤140 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sheath | Material | PVC(complies RoHS/REACH) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| External O.D. | 5.1±0.3 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Gray(RAL7046) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tensile strength | >13.5 Mpa | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.55±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Surface Printing | Letter height | 3.0±0.3 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Black | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Print error & Space | 1±0.005 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Case number | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing | Packing | Carton | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Once packing dimension | 350mm*216mm*350mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing dimension | 370mm*460mm*370mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing quantity | 2 cases | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing length | 305±1 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rip-cord | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Ambient temperature | -20℃～60℃ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SKU: n/a
Network Switches
NSW2010 Series
Support IEEE802.3 at standard, compatible with IEEE802.3 af by electrical equipment (PD)
Supports PoE Power up to 30W for each PoE port;
Auto detect power device; will not burned non-standard PoE device or normal PoE switch;
Supports port power supply prioritization, guarantee the continuous power supply of key nodes;
Supports IEEE802.3 x full duplex flow control and Backpressure half duplex flow control;
Line-speed forwarding, intelligent identification
Supports storage – and- forward for Data exchange;
Support RJ45 Auto-MDI/MDIX
SKU: n/a
WIFI Cameras
Uho-S2E
• High quality image with 2MP, 1/3″CMOS sensor
• 2MP (1920*1080)@25/20fps; 720P (1280*720) @25/20fps
• Ultra 265, H.265, H.264
• Built-in Mic & Speaker, support two-way audio, offer better interaction
• IR night vision, up to 10m (33ft) IR distance
• Support 256 G Micro SD card
• Wi-Fi connection and easy installation
SKU: n/a
WIFI Cameras
Uho-P1A-M3F4D
• High quality image with 3MP, 1/2.8″CMOS sensor
• 2304*1296@20fps in the main stream
• Ultra 265, H.265, H.264
• Support digital WDR (Wide Dynamic Range)
• Built-in Mic & Speaker, support two-way audio, offer better interaction
• Support sound and light warning, makes warning and alarming more noticeable
• Smart IR, up to 30 m (98 ft) IR and 10m (33 ft) warm light distance, suitable for more scenes
• Self-contained bracket, support two kinds of mounting
• Supports 256 GB Micro SD card
• Wi-Fi connection and easy installation
• IP66 ingress protection
• The front face is made of grapheme, which has better heat dissipation and more environmental protection
SKU: n/a
TV Entertainment
Go to Daily Deals SectionDVR & NVR
XVR301-16F
Support H.265/H.264 video formats
Support audio over coaxial cable(only for TVI cameras)
Support analog camera upgrade over coaxial cable
Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
16-channel BNC input
Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
HDMI and VGA simultaneous output
Long transmission distance over coaxial cable
Support mainstream cameras of ONVIF and RTSP protocols
SKU: n/a
Monitors & TV
MW-LC22
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 22” |
| Pixel Pitch（H*V）(mm) | 0.24*0.24 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Polish, Czech, Russian, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 493.06*382.69*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 557*370*140 |
| Weight（Kg） | Net Weight:2.3 Gross Weight:3.3 |
| Operation Temperature | 0°C ~ 40 °C |
| Operating Humidity | 20%~85% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Smartphones & Tablets
Go to Daily Deals SectionAnalog 2mp, Analog Cameras
UAC-B112-F28(40)-W
2MP ColourHunter Fixed Bullet Analog Camera
• 2MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
SKU: n/a
Analog 5mp, Analog Cameras
UAC-B115-AF28(40)
5MP Fixed IR Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 5mp, Analog Cameras
UAC-T115-AF28(40)
5MP Fixed IR Turret Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 5mp, Analog Cameras
UAC-B115-AF28(40)-W
5MP ColourHunter Fixed Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 8mp, Analog Cameras
UAC-D122-AF28(40)M
2MP LightHunter HD IR Fixed Dome Analog Camera
• High quality imaging with 2MP resolution
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• 3D noise reduction technology delivers clean and sharp images
• Supports 180° horizontal/vertical flip
• OSD configuration menu, easy to operate
• Water and dust resistant (IP67) and vandal-resistant (IK10)
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports digital defog
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• 3D noise reduction technology delivers clean and sharp images
• Supports 180° horizontal/vertical flip
• OSD configuration menu, easy to operate
• Water and dust resistant (IP67) and vandal-resistant (IK10)
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports digital defog
SKU: n/a
IP Camera 4mp, IP Cameras, Owlview
IPC2314LE-ADF28(40)KM-WP
4MP ColorHunter with Wise-ISP Fixed Bullet Network Camera
High quality image with 4MP, 1/1.8″CMOS sensor and F1.0 large aperture lens
4MP (2688*1520)@ 25/20fps; 4MP (2560*1440)@ 25/20fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps;
Ultra 265, H.265, H.264, MJPEG
Colorhunter with Wise-ISP technology ensures 24-hour full-color images
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic
White Light, up to 30m warm light distance
Supports 256 GB Micro SD card
IP67 protection
Support PoE power supply
3-Axis
SKU: n/a
IP Cameras, PTZ Camera
IPC6412LR-X16-VG
2MP 16x LightHunter Network PTZ Dome Camera
• High quality image with 2MP,1/2.8’’ CMOS sensor
• 1920*1080@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• 16X optical zoom allows for closer viewing of subjects
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100m (328ft) IR distance
• Micro SD, up to 256GB
• DC 12V±25% or PoE+ (IEEE 802.3at)
• IP66 ingress protection
• 1920*1080@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• 16X optical zoom allows for closer viewing of subjects
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100m (328ft) IR distance
• Micro SD, up to 256GB
• DC 12V±25% or PoE+ (IEEE 802.3at)
• IP66 ingress protection
SKU: n/a
DVR & NVR
XVR301-16F
Support H.265/H.264 video formats
Support audio over coaxial cable(only for TVI cameras)
Support analog camera upgrade over coaxial cable
Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
16-channel BNC input
Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
HDMI and VGA simultaneous output
Long transmission distance over coaxial cable
Support mainstream cameras of ONVIF and RTSP protocols
SKU: n/a
Monitors & TV
MW-LC22
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 22” |
| Pixel Pitch（H*V）(mm) | 0.24*0.24 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Polish, Czech, Russian, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 493.06*382.69*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 557*370*140 |
| Weight（Kg） | Net Weight:2.3 Gross Weight:3.3 |
| Operation Temperature | 0°C ~ 40 °C |
| Operating Humidity | 20%~85% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Monitors & TV
MW-LC24
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 24″ |
| Pixel Pitch（H*V）(mm) | 0.27*0.27 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Russian, Polish, Czech, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 540.38*417.55*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 601*400*145 |
| Weight（Kg） | Net Weight:3.4 Gross Weight:4.4 |
| Operation Temperature | 0°C ~ 50 °C |
| Operating Humidity | 10%~90% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Smart Interactive Display
MW3586-U-E
| Panel | Description |
| Backlight | DLED backlight |
| Panel size | 86 inches |
| Resolution | 3840*2160 |
| Brightness (cd/m²) | 350 |
| Contrast Ratio | 1200:1 |
| Response Time (ms) | 8 |
| Color Support | 1.07B |
| Viewing Angle (H/V) | 178°/178° |
| System | Description |
| CPU | RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G) |
| CPU Frequency | 2.4GHz |
| RAM/ROM | DDR4: 8GB eMMC: 64GB |
| System Compatibility | Android 12.0 |
| Touch | Description |
| Touch Control | Infrared touch screen, 20-point multi-touch at most |
| Touch Precision (mm) | ±1 |
| Recognizable Object | 5 points 2mm |
| Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare |
| Touch Response Time (ms) | ≤10 |
| Touchscreen Input | Opaque objects (e.g. finger, pen, etc.) |
| Interface | Description |
| Video Input | 3*HDMI IN (4K@60) |
| Video Output | 1*HDMI OUT (4K@60) |
| Audio Input | 1*AUDIO IN |
| Audio Output | 1*AUDIO OUT |
| Other Interfaces | 1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B |
| Network | 2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces |
| Audio | Description |
| Frequency domain | 80Hz～20kHz |
| Speaker | Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) |
| Wi-Fi | Description |
| WiFi Configuration | Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G |
| WiFi Performance | 30 m² coverage, 20m transmission distance in open space |
| Bluetooth | Description |
| Bluetooth Version | 5.2 |
| Bluetooth Performance | 10m transmission distance in open space |
| OSD | Description |
| Multi-Language | 24 (Simplified Chinese、Traditional Chinese、English、Japanese、Arabic、French、Spanish、Portuguese、German、Italian、Dutch、Polish、Korean、Catalan、Galician、Vietnamese、Bulgarian、Kazakh、Russian、Ukrainian、Thai、Uzbek、Hungarian、Croatian) |
| VESA | Description |
| Wall mount hole (mm) | 800*400 |
| Wall mount screw | 4-M8 screw hole |
| General | Description |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Overall Power Consumption （W） | ≤365 (on without OPS) |
| Standby Power Consumption （W） | ＜0.5 |
| Product Dimensions （W*H*D）（mm） | 1967*1173*89 |
| Package Dimensions （W*H*D）（mm） | 2117*1336*247 |
| Weight（Kg） | Net weight: 68.0 Gross weight:79.2 |
| Operating Temperature | 0 to 50°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage temperature | -20 to 60°C |
| Storage humidity | 0% to 95% (non-condensing) |
| Accessories Included | 1*power cord、2*touch pen、1*quick guide |
SKU: n/a
CCTV Cables
UTP Category 5E Cables
| Content of Data Sheet | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product model | CAB-LC2100A-IN/CAB-LC2100B-IN | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product specification | HSYV-5e 4×2×0.50 | |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Test Standard | YD/T1019-2013 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Conductor | Material | OFC(Oxygen free copper) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AWG | 24 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nom.O.D.(mm) | 0.5±0.005 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DC resistance | ≤95 Ω/km | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Insulation | Material | HDPE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.2±0.02 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Diameter | 0.9±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Blue/White- Blue | Green/White-Green | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Orange /White-Orange |
Brown/White-Brown | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pitch | Offset pitch | ≤25 mm |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Cable pitch | ≤140 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sheath | Material | PVC(complies RoHS/REACH) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| External O.D. | 5.1±0.3 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Gray(RAL7046) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tensile strength | >13.5 Mpa | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.55±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Surface Printing | Letter height | 3.0±0.3 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Black | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Print error & Space | 1±0.005 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Case number | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing | Packing | Carton | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Once packing dimension | 350mm*216mm*350mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing dimension | 370mm*460mm*370mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing quantity | 2 cases | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing length | 305±1 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rip-cord | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Ambient temperature | -20℃～60℃ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SKU: n/a
Network Switches
NSW2010 Series
Support IEEE802.3 at standard, compatible with IEEE802.3 af by electrical equipment (PD)
Supports PoE Power up to 30W for each PoE port;
Auto detect power device; will not burned non-standard PoE device or normal PoE switch;
Supports port power supply prioritization, guarantee the continuous power supply of key nodes;
Supports IEEE802.3 x full duplex flow control and Backpressure half duplex flow control;
Line-speed forwarding, intelligent identification
Supports storage – and- forward for Data exchange;
Support RJ45 Auto-MDI/MDIX
SKU: n/a
WIFI Cameras
Uho-S2E
• High quality image with 2MP, 1/3″CMOS sensor
• 2MP (1920*1080)@25/20fps; 720P (1280*720) @25/20fps
• Ultra 265, H.265, H.264
• Built-in Mic & Speaker, support two-way audio, offer better interaction
• IR night vision, up to 10m (33ft) IR distance
• Support 256 G Micro SD card
• Wi-Fi connection and easy installation
SKU: n/a
WIFI Cameras
Uho-P1A-M3F4D
• High quality image with 3MP, 1/2.8″CMOS sensor
• 2304*1296@20fps in the main stream
• Ultra 265, H.265, H.264
• Support digital WDR (Wide Dynamic Range)
• Built-in Mic & Speaker, support two-way audio, offer better interaction
• Support sound and light warning, makes warning and alarming more noticeable
• Smart IR, up to 30 m (98 ft) IR and 10m (33 ft) warm light distance, suitable for more scenes
• Self-contained bracket, support two kinds of mounting
• Supports 256 GB Micro SD card
• Wi-Fi connection and easy installation
• IP66 ingress protection
• The front face is made of grapheme, which has better heat dissipation and more environmental protection
SKU: n/a
Cameras
Go to Daily Deals SectionAnalog 2mp, Analog Cameras
UAC-B112-F28(40)-W
2MP ColourHunter Fixed Bullet Analog Camera
• 2MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
SKU: n/a
Analog 5mp, Analog Cameras
UAC-B115-AF28(40)
5MP Fixed IR Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 5mp, Analog Cameras
UAC-T115-AF28(40)
5MP Fixed IR Turret Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 5mp, Analog Cameras
UAC-B115-AF28(40)-W
5MP ColourHunter Fixed Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
SKU: n/a
Analog 8mp, Analog Cameras
UAC-D122-AF28(40)M
2MP LightHunter HD IR Fixed Dome Analog Camera
• High quality imaging with 2MP resolution
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• 3D noise reduction technology delivers clean and sharp images
• Supports 180° horizontal/vertical flip
• OSD configuration menu, easy to operate
• Water and dust resistant (IP67) and vandal-resistant (IK10)
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports digital defog
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• 3D noise reduction technology delivers clean and sharp images
• Supports 180° horizontal/vertical flip
• OSD configuration menu, easy to operate
• Water and dust resistant (IP67) and vandal-resistant (IK10)
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports digital defog
SKU: n/a
IP Camera 4mp, IP Cameras, Owlview
IPC2314LE-ADF28(40)KM-WP
4MP ColorHunter with Wise-ISP Fixed Bullet Network Camera
High quality image with 4MP, 1/1.8″CMOS sensor and F1.0 large aperture lens
4MP (2688*1520)@ 25/20fps; 4MP (2560*1440)@ 25/20fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps;
Ultra 265, H.265, H.264, MJPEG
Colorhunter with Wise-ISP technology ensures 24-hour full-color images
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic
White Light, up to 30m warm light distance
Supports 256 GB Micro SD card
IP67 protection
Support PoE power supply
3-Axis
SKU: n/a
IP Cameras, PTZ Camera
IPC6412LR-X16-VG
2MP 16x LightHunter Network PTZ Dome Camera
• High quality image with 2MP,1/2.8’’ CMOS sensor
• 1920*1080@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• 16X optical zoom allows for closer viewing of subjects
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100m (328ft) IR distance
• Micro SD, up to 256GB
• DC 12V±25% or PoE+ (IEEE 802.3at)
• IP66 ingress protection
• 1920*1080@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• 16X optical zoom allows for closer viewing of subjects
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100m (328ft) IR distance
• Micro SD, up to 256GB
• DC 12V±25% or PoE+ (IEEE 802.3at)
• IP66 ingress protection
SKU: n/a
DVR & NVR
XVR301-16F
Support H.265/H.264 video formats
Support audio over coaxial cable(only for TVI cameras)
Support analog camera upgrade over coaxial cable
Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
16-channel BNC input
Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
HDMI and VGA simultaneous output
Long transmission distance over coaxial cable
Support mainstream cameras of ONVIF and RTSP protocols
SKU: n/a
Monitors & TV
MW-LC22
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 22” |
| Pixel Pitch（H*V）(mm) | 0.24*0.24 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Polish, Czech, Russian, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 493.06*382.69*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 557*370*140 |
| Weight（Kg） | Net Weight:2.3 Gross Weight:3.3 |
| Operation Temperature | 0°C ~ 40 °C |
| Operating Humidity | 20%~85% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Monitors & TV
MW-LC24
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 24″ |
| Pixel Pitch（H*V）(mm) | 0.27*0.27 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Russian, Polish, Czech, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 540.38*417.55*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 601*400*145 |
| Weight（Kg） | Net Weight:3.4 Gross Weight:4.4 |
| Operation Temperature | 0°C ~ 50 °C |
| Operating Humidity | 10%~90% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
SKU: n/a
Smart Interactive Display
MW3586-U-E
| Panel | Description |
| Backlight | DLED backlight |
| Panel size | 86 inches |
| Resolution | 3840*2160 |
| Brightness (cd/m²) | 350 |
| Contrast Ratio | 1200:1 |
| Response Time (ms) | 8 |
| Color Support | 1.07B |
| Viewing Angle (H/V) | 178°/178° |
| System | Description |
| CPU | RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G) |
| CPU Frequency | 2.4GHz |
| RAM/ROM | DDR4: 8GB eMMC: 64GB |
| System Compatibility | Android 12.0 |
| Touch | Description |
| Touch Control | Infrared touch screen, 20-point multi-touch at most |
| Touch Precision (mm) | ±1 |
| Recognizable Object | 5 points 2mm |
| Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare |
| Touch Response Time (ms) | ≤10 |
| Touchscreen Input | Opaque objects (e.g. finger, pen, etc.) |
| Interface | Description |
| Video Input | 3*HDMI IN (4K@60) |
| Video Output | 1*HDMI OUT (4K@60) |
| Audio Input | 1*AUDIO IN |
| Audio Output | 1*AUDIO OUT |
| Other Interfaces | 1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B |
| Network | 2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces |
| Audio | Description |
| Frequency domain | 80Hz～20kHz |
| Speaker | Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) |
| Wi-Fi | Description |
| WiFi Configuration | Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G |
| WiFi Performance | 30 m² coverage, 20m transmission distance in open space |
| Bluetooth | Description |
| Bluetooth Version | 5.2 |
| Bluetooth Performance | 10m transmission distance in open space |
| OSD | Description |
| Multi-Language | 24 (Simplified Chinese、Traditional Chinese、English、Japanese、Arabic、French、Spanish、Portuguese、German、Italian、Dutch、Polish、Korean、Catalan、Galician、Vietnamese、Bulgarian、Kazakh、Russian、Ukrainian、Thai、Uzbek、Hungarian、Croatian) |
| VESA | Description |
| Wall mount hole (mm) | 800*400 |
| Wall mount screw | 4-M8 screw hole |
| General | Description |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Overall Power Consumption （W） | ≤365 (on without OPS) |
| Standby Power Consumption （W） | ＜0.5 |
| Product Dimensions （W*H*D）（mm） | 1967*1173*89 |
| Package Dimensions （W*H*D）（mm） | 2117*1336*247 |
| Weight（Kg） | Net weight: 68.0 Gross weight:79.2 |
| Operating Temperature | 0 to 50°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage temperature | -20 to 60°C |
| Storage humidity | 0% to 95% (non-condensing) |
| Accessories Included | 1*power cord、2*touch pen、1*quick guide |
SKU: n/a
CCTV Cables
UTP Category 5E Cables
| Content of Data Sheet | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product model | CAB-LC2100A-IN/CAB-LC2100B-IN | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product specification | HSYV-5e 4×2×0.50 | |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Test Standard | YD/T1019-2013 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Conductor | Material | OFC(Oxygen free copper) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AWG | 24 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nom.O.D.(mm) | 0.5±0.005 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DC resistance | ≤95 Ω/km | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Insulation | Material | HDPE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.2±0.02 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Diameter | 0.9±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Blue/White- Blue | Green/White-Green | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Orange /White-Orange |
Brown/White-Brown | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pitch | Offset pitch | ≤25 mm |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Cable pitch | ≤140 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sheath | Material | PVC(complies RoHS/REACH) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| External O.D. | 5.1±0.3 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Gray(RAL7046) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tensile strength | >13.5 Mpa | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Thickness | 0.55±0.05 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Surface Printing | Letter height | 3.0±0.3 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | Black | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Print error & Space | 1±0.005 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Case number | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing | Packing | Carton | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Once packing dimension | 350mm*216mm*350mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing dimension | 370mm*460mm*370mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Twice packing quantity | 2 cases | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing length | 305±1 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rip-cord | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Ambient temperature | -20℃～60℃ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SKU: n/a
Network Switches
NSW2010 Series
Support IEEE802.3 at standard, compatible with IEEE802.3 af by electrical equipment (PD)
Supports PoE Power up to 30W for each PoE port;
Auto detect power device; will not burned non-standard PoE device or normal PoE switch;
Supports port power supply prioritization, guarantee the continuous power supply of key nodes;
Supports IEEE802.3 x full duplex flow control and Backpressure half duplex flow control;
Line-speed forwarding, intelligent identification
Supports storage – and- forward for Data exchange;
Support RJ45 Auto-MDI/MDIX
SKU: n/a
WIFI Cameras
Uho-S2E
• High quality image with 2MP, 1/3″CMOS sensor
• 2MP (1920*1080)@25/20fps; 720P (1280*720) @25/20fps
• Ultra 265, H.265, H.264
• Built-in Mic & Speaker, support two-way audio, offer better interaction
• IR night vision, up to 10m (33ft) IR distance
• Support 256 G Micro SD card
• Wi-Fi connection and easy installation
SKU: n/a
WIFI Cameras
Uho-P1A-M3F4D
• High quality image with 3MP, 1/2.8″CMOS sensor
• 2304*1296@20fps in the main stream
• Ultra 265, H.265, H.264
• Support digital WDR (Wide Dynamic Range)
• Built-in Mic & Speaker, support two-way audio, offer better interaction
• Support sound and light warning, makes warning and alarming more noticeable
• Smart IR, up to 30 m (98 ft) IR and 10m (33 ft) warm light distance, suitable for more scenes
• Self-contained bracket, support two kinds of mounting
• Supports 256 GB Micro SD card
• Wi-Fi connection and easy installation
• IP66 ingress protection
• The front face is made of grapheme, which has better heat dissipation and more environmental protection
SKU: n/a
